510

Tool and technology database

7.

2 T

ool edit

or

Removing a cutting edge from the multipoint tool

Place the cursor on a cutting edge of the multipoint tool.

Press the soft key.

Press the soft key. The tool editor lists all cutting
edges of the multipoint tool.

Select the cutting edge.

Remove the cutting edge from the multipoint tool
chain.

Removing complete multipoint tools

Place the cursor on a cutting edge of the multipoint tool.

Press the soft key.

Press the soft key. The tool editor lists all cutting
edges of the multipoint tool.

Place the cursor on the cutting edge no. 0 of the
multipoint tool.

The multipoint tool chain is removed.
