74 QC-300 Series User’s Guide
Point constructed from a distance and a point
A point feature will be constructed and offset from the parent point fea-
ture by the parent distance feature.
To construct a point from a point and a distance:
1 Touch the Measure Point icon
2 Touch the point feature
3 Press the Enter key
4 Touch the distance feature
5 Press the Enter key
6 Press the Finish key
An offset point feature will be constructed.
Point constructed from a circle
A point feature will be constructed at the center of a circle.
To construct a point from a circle:
1 Touch the Measure Point icon
2 Touch the circle feature
3 Press the Enter key
4 Press the Finish key
A point feature will be constructed at the center of the circle.
