5
2
Installation
Chapter 2:
Installation
The QC-300 is easy to install in a variety of basic and advanced measurement applications. This chapter
describes how to unpack and install the QC-300. Repackaging instructions are also included for return
shipments and for distributors and OEM customers that are configuring a QC-300 and shipping it to an
end-user.
Unpacking the QC-300
Carefully remove the contents of the shipping carton.
NOTE
Save the carton and packaging materials in case future return shipment becomes
necessary.
Inspect the components listed below for shipping damage. The contents of the carton includes:
• QC-300 instrument • Mounting stand and hardware
• Power cord • Warranty registration card
Shipments of other optional equipment in separate cartons might include:
• Optical cables and press-clip • Plexiglas cable holder
• RS-232 serial cable • CNC output cable
• Foot switch • Taltech’s WinWedge ® software
If any components were damaged in shipment, save the packaging materials for inspection and contact
your shipping agent for mediation. Contact your Metronics distributor for replacement parts.
