Problem Solving
Probable cause 4: The wrong encoder is connected to the axis
Possible solutions:
1 Connect the axis encoder specified in the Encoders setup screen.
2 Confirm that the each encoder is connected to the correct axis input.
Probable cause 5: The wrong in/mm unit of measure is specified
Possible solution:
1 Specify the correct units of measure in the Encoders setup screen.
Probable cause 6: The wrong encoder reference mark is specified
Possible solution:
1 Correct the reference mark type in the Encoders setup screen.
Probable cause 7: Error correction is required to compensate
encoder inaccuracies:
Possible solutions:
1 Perform LEC, SLEC or optional NLEC error correction in the corresponding error screen.
2 Error correction was performed but not enabled. Enable error correction in the
LEC, SLEC or optional NLEC setup screen.
Probable cause 8: Edge detection is not calibrated:
Possible solution:
1 Perform a Teach operation or a Distance Cal using the Magnifications Setup screen.
Probable cause 9: Edge detector and crosshair probes are not
cross-calibrated:
Possible solution:
1 Perform a Cross Cal using the Magnifications Setup screen.
Probable cause 10: Multiple system magnifications are not
calibrated to be parcentric:
Possible solution:
1 Perform a Parcentric calibration using the Magnifications Setup screen.
Symptoms, Probable Causes & Solutions
