HEIDENHAIN ND 1300 OED and Crosshair Systems User Manual
Page 131
113
6
Measuring
Distances constructed between two rectangles
The distance feature will be constructed between the centers of two
rectangles.
To construct a distance between two rectangles:
1 Touch the Measure Distance icon
2 Touch the first rectangle Feature
3 Press the Enter key
4 Touch the second rectangle Feature
5 Press the Enter key
6 Press the Finish key
The distance feature will be constructed between the two rectangles.
Constructing Features
