Reference
Chapter 12:
Reference Material
This chapter contains technical information regarding:
• QC-300 product specifications
• Footswitch wiring
• RS-232 connector wiring
• Tolerances
Product specifications
Electrical
Input Voltage Range: 85 VAC to 264 VAC. 1.0 Amp maximum (Auto switching)
Fuse: 1.6 Amp 250 VAC Slow Blow 5 x 20 mm
Input Frequency: 43 Hz to 63 Hz
Environmental
Temperature: 0 °C to 45 °C (32 °F TO 113 °F) non-condensing
Humidity: 90% rh maximum
Altitude: 2000 meters (6,562 ft) maximum
Installation: Category: II
Dimensions
Enclosure (W x H x D): 29.2 cm x 19.1 cm x 7.0 cm (11.5” x 7.5” x 2.75”)
Base (W x H x D): 25.4 cm x 5.1 cm x 19.8 cm (10” x 2” x 7.8”)
Enclosure weight: 1.6 kg (3.5 lbs.)
Base weight: 3.2 kg (7 lbs.)
LCD
Size/color: 17.2 cm (6.8 inch) x 12.9 cm (5.1 inch) TFT color touch screen
Resolution: 800 x 600 pixels
ENC tests
EN61000-4-3, EN61000-4-4, EN61000-4-5, EN61000-4-6, EN61000-4-11, EN61000-4-2, EN61000-4-1
