26 QC-300 Series User’s Guide
Setup
The setup function provides access to all of the system setup screens required for configuring QC-300
measurement and operation. Touch the setup button to display the setup screen and menu. Access to the
setup menu is given through two introductory screens that show the software version, the system options
and a caution regarding the use of setup functions.
Setup screen tools will be made available to those who can provide a valid supervisor password.
NOTE
Detailed descriptions of all setup functions and tools are contained in
Chapter 10: Setup.
Printing reports and sending data
Measurement data shown on the DRO screen or contained
in the feature list can be printed in reports over the USB
port or sent to a computer over the RS232 serial port. In
either case, the printing of reports and the transmission of
measurement data is initiated by pressing the Print but-
ton.
NOTE
Report printing and data transmission
are configured in the Print setup screen
described in Chapter 10: Setup. Print-
ing and data transmission are described in Chapter 9: Communication.
