GASBOY Series 1000
6-20 03/07/03
Place pump/dispenser in auto position. Inside the Series 1000 post, place the pump
override switch in the AUTO position.
Possible Cause Checks Corrective Action
No AC feed through Series
1000. Authorize the pump. Using an
AC voltmeter, measure
between the neutral and the
output of the A contacts of the
pump power terminal block in
the Series 1000 post. Is
115VAC measured? Replace the relay for the A
contacts if 115VAC is not
measured at the output.
Replace the pump override
switch if replacing the relay did
not correct the problem.
