User’s Manual—SNAP™ 500 Gen 1 and Gen 2 89
9.5 Minimum Cut Length
Problem Probable Cause Corrective Action
Machine drops short
tickets between
knife and nip roller
assembly. Minimum
length is 0.725”,
18.42mm.
1) Knife out of alignment 1. Loosen knife bracket screws
shown in diagram.
2. Rotate knife towards nip roller
assembly.
3. Hold in place while tightening
screws.
.
1. Loosen
Screws
2. Rotate Knife
