User’s Manual—SNAP™ 500 Gen 1 and Gen 2 129
12.22 Turn Bar / Stacker Mount Assembly – Gen 2
ITEM PART NO. DESCRIPTION QTY
1 586003 SHAFT, INK TURN 6
2 588009 SHAFT, STACKER MOUNT 1
3 631201 KIT, FRAME ASSEMBLY, SNAP 500 2/1 1
4 638001 SHAFT, LONG STACKER MOUNT 1
5 991374 1/4 SCREW, 1/4-20 X 1/2 PAN PHILLIPS 2
6 991379 10-32 X 3/8 PHILLIPS PAN HEAD SCREW 6
NS 586010 STATIC BRUSH (INK ROLL) 3
