22 User’s Manual—SNAP™ 500 Gen 1 and Gen 2
1. Press and hold the Voice button until the printer says “Press Start for Test
Patterns.”
2. Press the Start button. The printer will say “Press Start for Test Pattern 1.” If
you want to print test pattern 1, press the Start Button then go to step 3. If you
want to print test pattern 2, press the Voice button. The printer will say “Press
Start for Test Pattern 2.” Press the Start button.
3. The printer will say “Ready to print test pattern 1 (or 2), Returning to print
mode.” At this time the Data light will come on. The printer is now ready to
print the test labels.
4. Ensure you have care label stock and thermal transfer ink ribbon loaded on the
top and bottom printing stations.
2.6.4 Printing the Test Labels
1. Press the Start button. The stacker (if installed) will move the platform to its start
position and the printer will begin printing the test labels.
2. If any problems occur, either the Supply or Error light will come on. If this
happens, press the Voice button and the printer will say a message telling what
the problem is. Correct the problem and press the Start button again. Repeat
this until the printer runs continuously.
3. If you can’t get the printer to run, refer to sections 9 and 10 troubleshooting.
