5.4 Installing the shielding plate
5 Installation
5.4 Installing the shielding plate 5400 Installing the shielding plate 5- Montage
 Installation materials: Unscrew the screws (see illustration) and re-use
them
 Required tool: Cross slot screwdriver
Fig. 5-3: Installing the shielding plate on the servo amplifier
