3-20 SV61311 Rev. E
3 • Basic Operation
Perform Length Adjustments (Inner Envelope Openers)
1. If using windowed envelopes, loosen the thumbscrews that secure each
Inner Envelope Opener.
NOTE: There are three Inner Envelope Openers, that typically need length
adjustments only. But, when needed, these (except the Middle Opener) can
be moved laterally.
Adjusting
the Envelope
Openers
(continued)
Figure 3.9.4: Inner Envelope Opener Locations
Inner Envelope
Opener
Thumbscrews
a. Position the Inner Envelope Openers so they do not touch the edge
of the window. In unusual circumstances, i.e., vertical windows, it
may be necessary to place the Opener on the window to prevent the
Opener from catching on the window's edge.
b. Tighten the thumbscrews for the adjusted Openers.
2. Press down then pull one of the knobs on the top of the frame to deter-
mine how far the the insertion edge of one Inner Envelope Opener goes
into the envelope.
