Pitney Bowes DI950 FastPac Inserter - Manual (Page 116)

6-4 SV61311 Rev. E
6 • Reference
Capacities
Tower Sheet/
Insert/Envelope
Feeders
• 350 20 lb. (80 gsm) sheets; 350 insert cards; 250 envelopes.
• Feeders are multi-purpose: they can handle sheets, cards, slips
and envelopes.
• Feeders, including envelope feeders, can be linked to increase
running time.
• Feeders are available in pairs of two (maximum four feeders).
Folder Up to 8 sheets of 20 lb. (80 gsm) material.
Accumulator Maximum collation thickness is 1/4" (6 mm).
High Capacity
Sheet Feeder
(HCSF)
Available in pairs. Capacity is 2,000 sheets per pair.
Drop Stacker 130 pieces, letter mail; 25 pieces, flat mail.
Vertical Power
Stacker
250 pieces, letter mail (assumes single sheet insert).
Production
Power Stacker
At least one USPS mail tray (two feet of finished mail).
Moistener/
Closer/Sealer
8,000 letters before refilling.
Component
Specifications
Folder
Fold Types
Top address
documents
C fold, Z fold, single
and double fold
Maximum number of
sheets per collation: 8
(20 lb. [80 gsm])
Bottom address
documents
(see Notes below)
C fold, Z fold and
single fold
Middle address
documents
(see Notes below)
C fold
Machine
Adjustments
None
No-Fold (Bypass) Yes
Notes
• Documents with addresses on the bottom may require the
Inverter kit.
• Documents with an address present on the middle of the sheet
always require the Inverter kit.
• Refer to the Avalable Fold Type/Address Locaton/
Envelope Type Combnatons table in this chapter for more
information.
