SV61311 Rev. E 6-5
Reference • 6
High Capacity Envelope Feeder (HCEF)
The HCEF is standard on the DI950 professional series; it is not available for the DI900
series.
Material
Letter-size envelopes
Material
Dimensions
Depth: 3.5" (89 mm) to 6.5" (165 mm)
Width: 8.5" (215.9 mm) to 10.5" (266 mm)
Capacity 500 letter-sized pieces, 24 lb. (90 gsm) weight.
Component
Specifications
(continued)
Scanning Capability (Optional)
The DI900/DI950 base module and the HCSF have an optional scanning capability for
reading ladder format OMR and barcode marks. The HCSF has an optional scanning
capability for reading picket format barcodes. The scanner kits are field installed.
OMR Codes
Supported
5-Series, 3-Series, SECAP ™ 2600, Pitney Bowes ® Console.
OMR Functions
Supported
Variable page documents; selective feeding; feeder-to-feeder
matching; force divert; mark for special handling.
Barcode Formats
Supported
Code 39 ™ (3 of 9); Interleaved 2 of 5.
Notes The horizontal position of the scanner is operator adjustable.
Documents from any feeder can be scanned.
Documents should be printed on a laser printer for scanning. Photo
copied documents and documents printed on an ink jet printer
cannot be scanned.
Available Fold Type/Address Location/Envelope Type Combinations
Fold Type
Address Location Envelope Type
C Fold Top Standard Flap
Middle Forward Flap
Bottom Bottom Flap
Middle * Standard Flap *
Z Fold Top Standard Flap
Bottom Bottom Flap
Bottom * Standard Flap *
Single Fold Top Standard Flap
Top Bottom Flap
Bottom Bottom Flap
Bottom Standard Flap
Double Fold Top Standard Flap
Third Panel * Standard Flap *
*This Fold Type/Address Location/Envelope Type combination requires an
inverter.
