2-22 SV61311 Rev. E
2 • Meet the Inserting System
About System
Covers
Three covers on the front side of the system, as shown in the figure below,
open to provide access to Paper Release Knobs.
Covers on the top of the Transport Deck open to provide access to the roll-
ers in the main paper path:
Post-fold
Accumulator
Cover
Insertion
Area
Cover
Figure 2.7.2: Top Covers
Pre-fold
Accumulator
Cover
Folder
Cover
Figure 2.7.1: Front Covers
Sealer Replacement
Cover
(closed)
Tower Base Cover
(closed)
Main Transport
Deck Cover
(open)
