SV61311 Rev. E 8-27
Scanning • 8
Direction of Feed
Clear Zone
Leading Edge
Trailing Edge
2 mm min.
3
mm
min.
3 mm
min.
3 mm
min.
3
mm
min.
Barcode Specification Diagram,
Ladder Orientation
(Diagram is not to scale)
Feeder Tower: 125 mm max.
HCSF: 105 mm max
Feeder Tower: 20 mm min.
HCSF: 32 mm min.
*1234567*
*1234567*
16
point
font
min.
17 mm min.
to clear zone
(dotted line),
20 mm min.
to barcode
17 mm min.
to clear zone
(dotted line),
20 mm min.
to barcode
*1234567* *1234567* *1234567*
*1234567* *1234567* *1234567*
*1234567*
Barcode
Specifications
(continued)
