EXFO FTB-800 Series for FTB-1 - Manual (Page 94)

Test Setup - Test Configurator, Timer, and System
84 FTB-700G/800 Series
Modify Structure Button
Modify Structure Button
From the Test menu, tap Setup, Test Configurator, and the Modify
Structure button.
For Transport Test Applications
TX/RX allows the configuration of the following parameters for either
TX/RX or TX and RX in Decoupled topology.

Interface/Rate: Select the desired interface rate. Choices depend on
the selected test and the rates available on themodule.
Test Interface/Rate
OTN OTU2 [10.709 Gbit/s]
OTU1e [11.049 Gbit/s]
OTU2e [11.096 Gbit/s]
OTU1f [11.270 Gbit/s]
OTU2f [11.318 Gbit/s]
OTU1 [2.666 Gbit/s]
SONET (Serial) OC-192 [9.953 Gbit/s]
OC-48 [2.488 Gbit/s]
OC-12 [622.08 Mbit/s]
OC-3 [155.520 Mbit/s]
OC-1 [51.840 Mbit/s]
STS-3e [155.520 Mbit/s]
STS-1e [51.840 Mbit/s]
SDH (Serial) STM-64 [9.953 Gbit/s]
STM-16 [2.488 Gbit/s]
STM-4 [622.080 Mbit/s]
STM-1 [155.520 Mbit/s]
STM-0 [51.840 Mbit/s]
STM-1e [155.520 Mbit/s]
STM-0e [51.840 Mbit/s]
