Specifications
NetBlazer 511
SFP CPRI/OBSAI Optical Interface
SFP CPRI/OBSAI Optical Interface
SFP FTTA INTERFACES
CPRI/OBSAI 2.4576/3.072 Gbit/s
Wavelength (nm) 850 1310 1310 1550
EXFO product number FTB-8590 FTB-8190 FTB-8191 FTB-8192
Tx level (dBm) –9 to –3 –5 to 0 –2 to 3 –2 to 3
Rx level sensitivity (dBm) –18 to 0 –18 to 0 –27 to –9 –28 to –9
Maximum reach 300 m on OM3 MMF 15 km 40 km 80 km
Transmission bit rate (Gbit/s) 2.4576/3.072 2.4576/3.072 2.4576/3.072 2.4576/3.072
Reception bit rate (Gbit/s) 2.4576/3.072 2.4576/3.072 2.4576/3.072 2.4576/3.072
Tx operational wavelength range (nm) 830 to 860 1270 to 1360 1280 to 1355 1500 to 1580
Measurement accuracy (uncertainty)
Optical power (dB)
±2 ±2 ±2 ±2
Max Rx before damage (dBm) +5 +5 +3 +3
Jitter compliance IEEE 802.3 GR-253 (SONET)
G-958 (SDH) GR-253 (SONET)
G-958 (SDH) GR-253 (SONET)
G-958 (SDH)
Laser type VCSEL DFB DFB CML
Laser product Class 1 Class 1 Class 1 Class 1
Connector LC LC LC LC
Transceiver type SFP SFP SFP SFP
