Test Setup - Test Configurator, Timer, and System
NetBlazer 173
RFC 2544 - Subtests

Max. Rate is the maximum rate the test should begin with, in terms of
a percentage of the line rate (%), Mbit/s, or Gbit/s. For Dual Test Set
Max. Rate is configurable for both local to remote (L -> R) and remote
to local (R -> L) directions.

Trial Duration is the time for each trial in minutes:seconds: 1 second
(default) to 30 minutes.
Interface
Speed
Max. Rate
% Mbit/s Gbit/s
10 Mbit/s 0.0050 to 100.0000 a
a. Default value.
0.00001 to 10.000 a Not Applicable
100 Mbit/s 0.0050 to 100.0000 a 0.0001 to 100.000 a Not Applicable
1000 Mbit/s 0.0050 to 100.0000 a 0.001 to 1000.00 a 0.000001 to 1.000 a
10G LAN 0.0050 to 100.0000 a 0.01 to 10000.000 a 0.00001 to 10.000 a
10G WAN b
b. The maximum value for 10G WAN may be lower depending on the frame size. The
maximum value will be adjusted for each frame size.
0.0005 to 92.8571 a 0.01 to 9285.71 a 0.00001 to 9.28571 a
