Test Results
340
FTB-700G/800 Series
Summary (1588 PTP)
Negotiation Status
The status of the PTP Negotiation is displayed while in Unicast
negotiation.
Negotiation
Status
Description
Background
Color
a
a.
The gray background color is also used for a Link Down.
Request Granted All the Signaling request types have been granted.
Green
[Message type]
Request Denied
The Signaling grant message has not been granted.
Red
Session
Canceled
The Grand Master has canceled the Unicast session.
Red
No Reply
No message is received from the Grand Master
following transmission of 3 Signaling requests for a
message type.
Make sure that both IP address and Domain (refer to
1588 PTP on page 96) of the Grand Master Clock are
valid as well as the IP address of the unit’s port used to
connect on the network (refer to Network on
Red
Pending
Unicast negotiation has started and no message has
been received from the Grand Master.
Gray
Inactive
The Unicast negotiation is not active.
Gray
