Test Results
NetBlazer 379
Traffic - Flow Control
Pause Injection
Note: Pause injection is only available for Traffic Gen & Mon test application.

Packet Pause Time: Enter the pause time value to be transmitted in
Quanta or Microsecond (default is 100 Quanta).
Note: When entering a value in μs it will be rounded to the closest multiple of
0.0512 for 10 Gbit/s, 5.12 μs for 100 Mbit/s, 0.512μs for 1000 Mbit/s, and
0.0512μs for 10 Mbit/s, .

Inject button allows to generate the defined packet pause time.

Destination MAC Address check box, when selected (cleared by
default), enables and allows to set the destination MAC address. The
default destination MAC address is the control protocol multicast
address: 01:80:C2:00:00:01.
Interface
Range
Quanta μs
10 Mbit/s 0 to 65535 0 to 3355392
100 Mbit/s 0 to 65535 0 to 335539.2
1000 Mbit/s 0 to 65535 0 to 33553.92
10 Gbit/s 0 to 65535 0 to 3355.392
