Specifications
NetBlazer 513
SFP+ Ethernet Optical Interfaces
SFP+ Ethernet Optical Interfaces
SFP+ ETHERNET OPTICAL INTERFACES
Transceiver type 10G Base-SR/SW 10G Base-LR/LW 10G Base-ER/EW
Wavelength (nm) 850 1310 1550
Model FTB-8690 FTB-8691 FTB-8692
Tx level (dBm) –5 to –1 –8 to 0.5 –4.7 to 4.0
Rx level sensitivity (dBm) –11.1 –12.6 –14.1
Maximum reach 300 m 10 km 40 km
Tx bit rate (Gbit/s) 9.95 to 10.3 9.95 to 10.3 9.95 to 10.3
Rx bit rate (Gbit/s) 9.95 to 10.3 9.95 to 10.3 9.95 to 10.3
Tx operational wavelength range (nm) 840 to 860 1260 to 1355 1530 to 1565
Measurement accuracy (uncertainty)
Frequency (ppm) ±4.6 ±4.6 ±4.6
Maximum Rx before damage (dBm) a 6 5 5
Jitter compliance IEEE 802.3ae IEEE 802.3ae IEEE 802.3ae
Laser type VCSEL DFB CML
Laser product Class 1 Class 1 Class 1
Connector b LC LC LC
