Specifications
NetBlazer 515
SFP Fibre Channel Interfaces
SFP Fibre Channel Interfaces
SFP FIBRE CHANNEL INTERFACES
FC-1Ч/2Ч/4Ч
Wavelength (nm) 850 1310 1310 1550
Model FTB-85912 FTB-85913 FTB-85914 FTB-85915
Tx level (dBm) –9 to –2.5 –8.4 to –3 0 to 5 1 to 5
Rx level sensitivity (dBm) –15 at FC-4 –18 at FC-4 –18 at FC-4 –16.5 at FC-4
–18 at FC-2 –21 at FC-2 –21 at FC-2 –20.5 at FC-2
–20 at FC-1 –22 at FC-1 –22 at FC-1 –22 at FC-1
Maximum reach (FC-1) 500 m on 50/125 μm MMF
300 m on 62.5/125 μm MMF 4 km 30 km 40 km
Transmission bit rate (Gbit/s) 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25
Reception bit rate (Gbit/s) 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25 1.06/2.125/4.25
Tx operational wavelength range (nm) 830 to 860 1260 to 1350 1285 to 1345 1544.5 to 1557.5
Measurement accuracy (uncertainty)
Frequency (ppm)
Optical power (dB)
±4.6
±2 ±4.6
±2 ±4.6
±2 ±4.6
±2
Max Rx before damage (dBm) 3 3 3 3
Jitter compliance ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2
FC classification ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2 ANSI FC-PI-2
Laser type VCSEL Fabry-Perot DFB DFB
Laser product Class 1 Class 1 Class 1 Class 1
Connector LC LC LC LC
