Test Results
354 FTB-700G/800 Series
Summary (ISDN PRI)
The Pass/Fail verdict icon is displayed on the top right corner of a channel
button as follows.
Channel
This section at the right of the channel buttons, displays information on the
selected channel.

Call Reference is a unique value assigned to an established call.

The icon next to Call Reference indicates whether the call is incoming
or outgoing followed by the duration of the call. An incoming call has
an arrow pointing towards the receiver whereas, for an outgoing call
the arrow points outwards.

The Call Timer next to the incoming/outgoing call icon displays the
duration of a call.

Calling Number indicates the number of the calling party.

Called Number indicates the number of the called party.

BERT

Alarms, see BER on page 249 for more information.

Errors, see BER on page 249 for more information.
Verdict Call Description
Pass Data BER result value meets the configured
threshold criterion and the call
establishment/termination succeeded.
Speech or 3.1 kHz The call establishment/termination
succeeded.
Fail Data BER result value does not meet the
configured threshold criterion and/or the call
establishment/termination failed.
Speech or 3.1 kHz The call establishment/termination failed.
