Physical Interfaces and LEDs
NetBlazer 15
Port Availability on the NetBlazer Modules
10G
(PORT #1)
Optical IN/OUT port SFP+
OC-192/STM-64 FTB-810G
AUX Future use FTB-810/
810G/880
ETHERNET
10/100/1000M
(PORT #1 and
PORT #2)
Electrical Ethernet port RJ-45:
Ethernet 10/100/1000 Mbit/s (electrical)
FTB-720G/
720G
+
/730G/
730G
+
/860/
860G/860GL
a
ETHERNET
100/1000M
(PORT #1 and
PORT #2)
Optical IN/OUT port small form factor pluggable (SFP):
Ethernet 100 Mbit/s (optical), Ethernet 1000 Mbit/s
(optical)
CPRI/OBSAI 2.4576/3.072 Gbit/s (optical)
b
Fibre Channel 1X/2X/4X
FTB-720G/
730G/860/
860G/860GL
a
/
ETHERNET
10G
(PORT #1)
Optical IN/OUT port 10G small form factor pluggable
(SFP+):
Ethernet 10 Gbit/s
Fibre Channel 8X/10X
FTB-860G/
860GL
a
EXT CLK Electrical port BNC for external clock synchronization:
DS1/1.5M/E1/2M/2 MHz/1PPS All
a. Only one port is available on the FTB-860GL module. The FTB-860GL module does not support Fibre
Channel and CPRI/OBSAI test applications.
b. OC-x/STM-x/OTU1 and CPRI/OBSAI are only available on PORT #1.
Port labelled Description and Supported signal(s) Module
