Test Setup - Test Configurator, Timer, and System
152 FTB-700G/800 Series
MAC/IP/UDP
Modify Frame Structure
Allows to modify the structure of the frame.

Global Option
12
IP Version allows to select IPv4 (default) or IPv6 that will be used for
both the interface and streams/services.

Framing

Frame Format (layer 2) allows to select Ethernet II (default) or
802.3 SNAP
1
as the frame format.

Network Layer (layer 3) sets the network traffic type:
IPv4 (default)/IPv6
1
, or None.

Transport Layer is disabled when the Network Layer is None.

MPLS
12
- The MPLS Label check box, when selected (cleared by
default), enables 1 or 2 MPLS labels allowing management and test
frames to be transmitted and received.

VLAN - The VLAN Tag check box when selected (cleared by default),
enables up to 3 stacked VLAN.
See VLAN on page 154 for additional VLAN settings.
1. Only available for 10M to 10G.
2. Only available with EtherSAM and Traffic Gen & Mon test applications.
Test Application Transport Layer
EtherSAM None, UDP (default), TCP
1
RFC 2544 UDP
EtherBERT UDP (default), TCP
1
Traffic Gen & Mon None, UDP (default), TCP
1
