Test Setup - Test Configurator, Timer, and System
184 FTB-700G/800 Series
S-OAM
Continuity Check

CC Function check box when selected (default) allows to transmit and
monitor CCM frames.
The following parameters are only configurable when the CC Function
check box is cleared.

Address Type defines the destination address type of the CCM frames:
Unicast or Multicast (default).

Priority
1
allows to select the VLAN user priority: 0 to 7 (default). Refer
to VLAN ID and Priority on page 575 for more information.

Drop Eligible
1
is set to No (no frames will be dropped when
congestion occurs) and is not configurable.

Period determines the transmission period of the CCM frame: 3.33 ms,
10 ms, 100 ms (default), 1 s, 10 s, 1 min, or 10 min.
Test Function
Note: Test Function parameters are not configurable when the TX Enable check
box is selected.

Function allows the selection of the test function to be performed.

Loopback (default) function is used to verify the bidirectional
connectivity to a peer MEP (Continuous check box cleared) and to
verify its capability to sustain close to line rate traffic (diagnostic
test; Continuous check box selected).

Test function is used to generate a test signal and/or verify the
integrity of received test signal from the peer MEP.

Frame Delay function is used to measure the round trip delay with
the peer MEP.
1. Available when VLAN is enabled (see VLAN on page 168).
