Test Control
NetBlazer 465
Discover Remote Button

Status indicates the status of the remote module.

Loop Up and Loop Down buttons

Loop Up establishes the connection with the selected remote
module and sets the remote module into Smart Loopback test
application.
If a remote module is in any busy status a user confirmation is
required to proceed with the Loop Up command.
Following a successful loop up, the IP address of the remote
module will be used as the destination IP address for the test.
Once the connection is established with the remote module, the
local module can be set for EtherSAM, RFC 2544, EtherBERT, or
Traffic Gen & Mon testing.

Loop Down ends the connection between the local and the
remote modules.
Status Description
Idle-
a
a. Possible test applications: EtherSAM, RFC 2544, EtherBERT, Traffic Gen & Mon,
Smart Loopback, Through Mode, TCP Throughput, Carrier Ethernet OAM,
Cable Test, 1588 PTP, or SyncE.
The specified test application is
selected but not running.
Busy-
b
b. Possible test applications: EtherSAM, RFC 2544, EtherBERT, Traffic Gen & Mon,
Smart Loopback, TCP Throughput, Carrier Ethernet OAM, 1588 PTP, or SyncE.
The specified test application is
running.
Not Responding No response from the specified IP
address (only possible when Target is
set to Specific IP).
