Test Setup - Test Configurator, Timer, and System
170 FTB-700G/800 Series
RFC 2544 - Global
Subtests and Estimated Time

Subtests allows to individually enable the Throughput, Back-to-Back,
Frame Loss, and Latency subtests.

Estimated Time (H:MM) indicates the estimated time required to
complete each subtest at best conditions. The total estimated time to
complete all subtests is also displayed.
Frame Distribution

Frame Distribution allows to select either RFC 2544 (default) or User
Defined distribution.

Quantity is only available when User Defined is selected and allows to
select the number of frames, from 1 to 7 (default), in the distribution.

Frame Size (Bytes): For RFC 2544 distribution, gives predefined frame
size distribution values. For User Defined distribution, enter up to
seven frame size values.
Distribution Frame Size
RFC 2544 64
a
,128, 256, 512, 1024, 1280, and 1518
a. The minimum frame size will be adjusted according to the frame structure and
components selected.
User Defined 64
a
to 16000
b
b. The maximum frame size is limited to 10000 for 10/100/1000Mbps electrical
interface.
