Specifications
508 FTB-700G/800 Series
SFP SONET/SDH and OTN Optical Interfaces
SFP SONET/SDH and OTN Optical Interfaces
a.
b.
c. To avoid exceeding the maximum receiver power level before damage, an attenuator must be used.
External adaptors can be used for other types of connectors.
SFP+ compliance: The FTB-700G/800 Series selected SFP+ shall meet the requirements stated in the SFP-8431 “Enhanced Small Form-Factor Pluggable Module
SFP+” Transceiver Multisource Agreement (MSA).” The FTB-700G/800 Series selected SFP+ shall meet the requirements stated in the “Specification for Diagnostic
Monitoring Interface for Optical Xcvrs.”
SFP c SONET/SDH AND OTN OPTICAL INTERFACES
Transceiver type OC-3/STM-1 OC-12/STM-4 OC-48/STM-16/OTU1
Reach and wavelength 15 km; 1310 nm 40 km; 1310 nm 40 km; 1550 nm 80 km; 1550 nm 15 km; 1310 nm 40 km; 1310 nm 40 km; 1550 nm 80 km; 1550 nm 15 km; 1310 nm 40 km; 1310 nm 40 km; 1550 nm 80 km; 1550 nm
Model FTB-8190 FTB-8191 FTB-8193 FTB-8192 FTB-8190 FTB-8191 FTB-8193 FTB-8192 FTB-8190 FTB-8191 FTB-8193 FTB-8192
Tx level (dBm) –5 to 0 –2 to 3 –5 to 0 –2 to 3 –5 to 0 –2 to 3 –5 to 0 –2 to 3 –5 to 0 –2 to 3 –5 to 0 –2 to 3
Rx operating range (dBm) –23 to –10 –30 to –15 –23 to –10 –30 to –15 –22 to 0 –27 to –9 –22 to 0 –29 to –9 –18 to 0 –27 to –9 –18 to 0 –28 to –9
Transmit bit rate 155.52 Mbit/s ± 4.6 ppm 622.08 Mbit/s ± 4.6 ppm
2.48832 Gbit/s ± 4.6 ppm
2.66606 Gbit/s ± 4.6 ppm
Frequency offset
generation (ppm)
±50 ±50 ±50
Receive bit rate 155.52 Mbit/s ± 100 ppm 622.08 Mbit/s ± 100 ppm
2.48832 Gbit/s ± 100 ppm
2.66606 Gbit/s ± 100 ppm (OTU1)
Operational
wavelength range (nm) 1261 to
1360
1263 to
1360
1430 to
1580
1480 to
1580
1270 to
1360
1280 to
1335
1430 to
1580
1480 to
1580
1260 to
1360
1280 to
1335
1430 to
1580
1500 to
1580
Spectral width 1 nm (–20 dB) 1 nm (–20 dB) 1 nm (–20 dB)
Measurement accuracy
(uncertainty)
Frequency (ppm)
Optical power (dB) ±4.6
±2
±4.6
±2
±4.6
±2
Maximum Rx
before damage (dBm)
a
3 3 3
Jitter compliance
GR-253 (SONET)
G.958 (SDH)
GR-253 (SONET)
G.958 (SDH)
GR-253 (SONET)
G.958 (SDH)
G.8251 (OTN)
Line coding NRZ NRZ NRZ
Laser product Class 1 Class 1 Class 1
Connector b LC LC LC
