Test Setup - Test Configurator, Timer, and System
NetBlazer 193
Services - Profile
Note: The CIR value will be calculated on the basis of the selected service profile
and the value entered in the Number of Calls or Number of Channels
field.

Frame Size (Bytes) indicates the frame size for Voice and Video
profiles and allows to change the frame size for Data profile:
Fixed (default)
Profile and
Codec
Type
Frame Size (bytes)
IPv4 IPv6
Voice Codec:
- VoIP G.711
- VoIP G.723.1
- VoIP G.729
Fixed
138
82
78
158
102
98
Video Codec:
All
Fixed 1374 1394
Data Fixed (default) 64
a
(default) to 10000
a. The minimum value is adjusted according to the frame structure and components
selected as shown in the following table.
Random 64
a
to 1518
b
b. The maximum frame size vale is adjusted for each enabled VLAN (+4 bytes per
VLAN).
EMIX 64
a
to 10000
