Selecting and Starting a Test
70 FTB-700G/800 Series
Ethernet Test Applications
3c. Tap the protocol block 1
to configure the frame structure and its
parameters (refer to page 78).
3d. Tap the test block
2
to configure the specific test settings (refer to
page 78).
3e. Tap the clock block to configure the clock synchronization (refer
to Clock on page 110).
4. Tap the Timer tab to automatically start and/or stop the test at a given
time or for a specific duration (refer to Timer on page 234).
5. For additional test configurations refer to Test Functions on page 385.
6. Tap the Start button from the right navigation bar to start the test (refer
to Start/Stop Button on page 492). The Summary result page will be
automatically displayed when the test is started from any Setup
configuration page. For additional results refer to Test Results on
page 241.
7. Depending on the test, when the test ends automatically or manually
stopped, the generate report pop-up is displayed by default. If required,
tap Yes to generate a report of the test results and statistics (refer to
Report Button on page 481 for more information).
1. Not available with Smart Loopback, Through Mode, TCP Throughput, and Cables Test.
2. Not available with Traffic Gen & Mon and Through Mode.
