Specifications
512 FTB-700G/800 Series
SFP Ethernet Optical Interfaces
SFP Ethernet Optical Interfaces
SFP ETHERNET OPTICAL INTERFACES
Two ports: 100M and GigE
Available wavelengths (nm) 850, 1310 and 1550
Model FTB-85910 FTB-85911 FTB-8590 FTB-8190 FTB-8192 FTB-8596 FTB-8597
Transceiver type 100 Base-FX 100 Base-LX 1000 Base-SX 1000 Base-LX 1000 Base-ZX 1000 Base-BX10-D 1000 Base-BX10-U
Wavelength (nm) 1310 1310 850 1310 1550 Tx: 1490
Rx: 1310
Tx: 1310
Rx: 1490
Tx level (dBm) –20 to –15 –15 to –8 –9 to –3 –9.5 to –3 0 to 5 –9.5 to –3 –9.5 to –3
Rx level sensitivity (dBm) –31 –28 –20 –22 –22 –20 –20
Maximum reach 2 km 15 km 550 m 10 km 80 km 10 km 10 km
Transmission bit rate (Gbit/s) 0.125 0.125 1.25 1.25 1.25 1.25 1.25
Reception bit rate (Gbit/s) 0.125 0.125 1.25 1.25 1.25 1.25 1.25
Tx operational wavelength range (nm) 1280 to 1380 1261 to 1360 830 to 860 1270 to 1360 1540 to 1570 1480 to 1500 1260 to 1360
Measurement accuracy (uncertainty)
Frequency (ppm)
Optical power (dB) ±4.6
±2
±4.6
±2
±4.6
±2
±4.6
±2
±4.6
±2
±4.6
±2
±4.6
±2
Maximum Rx before damage (dBm) a 3 3 6 6 6 6 6
Jitter compliance ANSI ×3.166 IEEE 802.3 IEEE 802.3 IEEE 802.3 IEEE 802.3ah IEEE 802.3ah
Ethernet classification ANSI ×3.166 IEEE 802.3 IEEE 802.3 IEEE 802.3 IEEE 802.3ah IEEE 802.3ah
Laser type LED FP VCSEL FP DFB DFB FP
Laser product Class 1 Class 1 Class 1 Class 1 Class 1 Class 1 Class 1
Connector b LC LC LC LC LC LC LC
