Test Results
NetBlazer 363
Summary (S-OAM)

TX CCM indicates the count of transmitted CCM frames.

RX CCM indicates the count of received CCM frames having their
source MAC address matching the Peer MEP MAC address, the
destination MAC address matching either the unit port Unicast MAC
address or a Multicast class 1 address
1
, and VLANs matching the unit
port VLANs.

CCM indicates the content of the last received CCM frame including
MEG ID (Y.1731), Domain ID (802.1ag and MEF), MA Name (802.1ag
and MEF), MEG Level (Y.1731 and MEF), MD Level (802.1ag), MEP ID,
and Period.
For unsupported Domain ID, MA Name, and MEG ID, the Unexpected
Format message is displayed.
1. Refer to Unicast/Multicast Addresses for S-OAM on page 574 for more information.
Supported Formats
Domain ID 1 (No Maintenance Domain Name present)
4 (Character String)
MA Name 2 (Character String)
MEG ID 32 (ICC based format)
