Rear Axle
When to Check Lubricant
Refer
to
lhe Maintenarice Schedute to determine how
often to check the lubricant. See Part
A: Scheduied
M uinie-nance Services on page 6-4.
How to Check Lubricant
If you have tne i500 Series^ me proper level la from
inch i[15 mm) to 1 5/& inch [40 mm) belQw the
bottom of the filler plug hole. The proper level for the
a BOO and 3500 Serins U from 0 to 1/4 (6 mm} below the
bottom of the tiller plug hole Add only enough fluid to
reach lhe proper
I
eve
\.
What to Use
Refer to the Maioieoance Schedule [o determine rA/hat
kind of fubricahf tc use, Sae Part D:
RecofUfnsnded
Flisids and Lutyncants on page 6-i7,
To get an accurate reading, the vehicle should he on a
level surface.
5-60
