Climate Controls
Climate Control System
With №is systerrt you can control the heating, cooling
and vènti laUcn ior your vehicle.
№ 1 >
1Л . -
^ ;
Hf ^ -J,. I
II [щ: ! I
Turn (he right knob clockwlBO or counierdockwise to
direct Ihc aiiilpw Inside ct yqur vs hide.
Tc change Ihs current mecle, selecl one □! the lolloping:
P (Vent)t This mode directs air to the insirumenl panel
outlets.
[Bt"LevelJ: This mode directs approKimalely half ol
1 he air to the irrstrumer^t panel outlets, then directs most
ol the remaining air to the fictor outlets Some air may be
directed toward the windshield.
(Floor): This mode directs most of №e air to the
Fleer outlets with same air directad Iq Ihs outboard
outlets (tor the side windows) and some air directed to
the windshield.
The right knob can atso be used to select the delrost
mode. Inlormaticn on deFogging and delro&ting can
be tour\d later in ihis seclion.
(Fan); Tern the left knob cloct^wisa or
counterdocfcwtbe to Increase or decrease Ihe fan speed.
If your vehicle has air conditioning, your healng/air
condiEbning controls will loch like this:
On hot days, open the windows to lei liot inside air
escape; then close them. This helps To reduce ihe Time
■It Lakes tor your vehicle to cool down. Il also hetps
the system to operaie mere etficifintly.
3 - 1 В
