Standard Flowmeters - Each standard flowmeter
has a standard range that it can accurately
measure. To change ranges requires changing
flowmeters.
Rapid Check Flowmeters - Similar to a standard
flowmeter but has several different “inserts”, each
with a different effective range, that can be
installed. To change the range of the flowmeter
just remove one insert and insert one having the
desired flow range.
GSO - Ground Speed Override is a minimum applica-
tion speed. When the vehicle speed drops below
GSO, the Control Console controls the output to the
GSO speed. Area is accumulated at the actual
ground speed.
Hydraulic Servo Control Valve – The term used to
describe a control valve that is capable of receiving
and acting upon increase and decrease information
from the Control Console and in turn controls the
flow of hydraulic fluid.
Impeller - A metallic device, similar to a propeller,
used in a flowmeter to monitor the liquid flow.
Liquid flowing past the impeller causes it to turn. A
magnet sensor, placed near the flowmeter wall,
senses the impeller blades as they pass and gener-
ates pulses to be sent to the control console.
Implement Status Switch - Provides another means
to stop the spraying operation. This switch may
take the form of a foot swich or an implement
switch mounted on the toolbar that opens a circuit
as the tool bar is raised, effectively stopping the
spraying operation..
Liquid Flow Control Valve – The term used to
describe a control valve that is capable of receiving
and acting upon increase and decrease information
from the Control Console and in turn controls the
flow of liquid product.
Master switch - A control switch that allows the
operator to turn on and off all active booms with
one switch.
