2-2
TASC 6100
98-05018
R2
CE & S
TANDARD
V
ERSION
C
HANGING
U
NITS
A. Set the console switches to the following positions:
1. Power ON
2. Mode Selector OPERATE
3. Display selector Speed
The display shows the current speed units.
B. Hold down the INC./DEC. switch for approximately
5 sec. The display alternates between MPH (US) and
KPH (Metric). Release the switch when the mode
that you desire is being displayed.
DISPLAY SELECTOR
Speed
Area Impl. Width
Distance
Test
Speed
PSI/Prime
Total Applied
Application Rate
OFF SET- UP DEC.
ON OPERATE INC.
Scan
Product Vol.
Fan RPM
BOOMS
1 2 3 4 5 6 7 8 9
% Rate
A-1
A-2
A-3
B
U NITS F OR E ACH D ISPLAY S ELECTOR S WITCH P OSITION
(Liquid Mode)**
POSITION US METRIC
Speed Miles/Hour (mph) Kilometers/Hour (kmph)
Field Area Acres (acre) Hectares (ha)
Total Area Acres (acre) Hectares (ha)
Product Vol. US Gallons (gal.) Liters (l)
Appl. Rate US Gallons/acre (gpa) Liters/Hectare (l/ha)
Total Applied US Gallons (gal.) Liters (l)
Impl. Width Inches - Feet (in., ft.) Meters (m)
Distance Feet - Miles (ft.-miles)* Meters - Kilometers (m-km)*
Test Speed Miles/Hour (mph) Kilometers/Hour (kmph)
U
NITS
F
OR
E
ACH
D
ISPLAY
S
ELECTOR
S
WITCH
P
OSITION
(Granular Mode)**
POSITION US METRIC
Speed Miles/Hour (MPH) Kilometers/Hour (KPH)
Field Area Acres (Ac) Hectares (-Ha)
Total Area Acres (Ac) Hectares (-Ha)
Product Vol. Pounds (lb) Kilograms
Appl. Rate pounds/Acre (lb/Ac) Kilograms/Hectare (-Ha)
Total Applied Pounds-Tons (lb -Tons) Kilograms-Metric Tons
Impl. Width Inches-Feet (In.-Ft.) Meters (Meters)
Distance Feet-Miles (Ft.)* Meters-Kilometers (Meters)*
Test Speed Miles/Hour (MPH) Kilometers/Hour (KPH)
Prod. Density Pounds/Cubic Ft. (Cu Ft.) Kilograms/Tenths Meter 3 (Meters Cu)
* No units displayed after roll over of feet to miles or meters to kilometers
** Items in parenthesis are the abbreviations that appear on the screen.
