TeeJet TASC-6100 - Manual (Page 46)

3-4
TASC 6100
98-05018
R2
CE & S TANDARD V ERSION
A. Set the console switches to the following posi-
tions:
1. Power ON
2. Mode Selector OPERATE
3. Display Selector PSI/Prime
B. Five dashes (- - - - -) appear on the display. (If in
pressure based mode the display reads Pr - - -.)
C. Hold the INC./DEC. switch up for about three
seconds. The main control valve moves to full
open and the display reads (OPEN). While
operating in this mode, there is no accumulation of
area, distance or carrier.
D. The main pump can be run, with the booms or
handgun open, to prime the sprayer. The control
valve remains open.
E. To resume normal spraying, hold the INC./DEC.
switch down for three to five seconds to close the
control valve (the display reads CLOSE), or move
the Display Selector switch away from the PSI/
Prime position.
R
APID
U
NLOAD
U
SING
T
HE
C
ONVEYOR
(Granular Application)
U
se the following procedure to operate the
spreader conveyor at maximum speed.
A. Set the console switches to the following positions:
1. Power ON
2. Mode Selector OPERATE
3. Display Selector PSI/Prime
B. Five dashes (- - - - -) appear on the display.
C. Hold the INC./DEC. switch up for about three
seconds. The display reads “OPEN” and the
hydraulic control valve moves to full open and
remains there. While operating in this mode, there
is no accumulation of area, distance or product.
DISPLAY SELECTOR
Speed
Field Area Impl. Width
Distance
Test
Speed
Prime
Total Applied
Application Rate
OFF SET- UP DEC.
ON OPERATE INC.
Scan
Product Vol.
Total Area
BOOMS
1 2 3 4 5 6 7 8 9
A-3
A-2 C
% Rate
A-1
DISPLAY SELECTOR
Speed
Area Impl. Width
Distance
Test
Speed
PSI/Prime
Total Applied
Application Rate
OFF SET- UP DEC.
ON OPERATE INC.
Scan
Product Vol.
Fan RPM
BOOMS
1 2 3 4 5 6 7 8 9
% Rate
A-1
A-2
A-3
C
