G. Stop the vehicle at the measured distance end marker.
Compare the distance indicated by the console to the
actual measured distance, to determine how much
correction is necessary. For example: if the indicated
distance is 396 Ft. after driving over a 400 foot
range, the error in the distance calibration is 1.0%.
H. Calculate the new distance calibration number using
the following formula:
Example:
NOTE: Use the same equation, regardless of the type of
distance sensor .
I. Enter the corrected cal. # using the switch settings
shown in the “G
ENERAL
C
ONSIDERATIONS AND
I
NITIAL
C ALIBRATION N UMBERS ” section above. Switch back to
the OPERATE mode. The distance accumulator
should now agree with the measured distance that
you traveled. If it doesn't , recheck your calculations.
R ECORD THIS CALIBRATION NUMBER
ON LAST PAGE OF MANUAL
.
S
ETTING
T
HE
H
OLD
/C
LOSE
R
ESPONSE
O
F
T
HE
F
LOW
C
ONTROL
V
ALVE
T
he operator can select a "Hold" or "Close" response
of the flow control valve to both “Implement
Status switch” and “All Booms OFF" conditions.
These responses are independent of each other, allowing
the operator to select a "Hold" condition for one and a
"Close" for the other. Careful consideration should be
given to both conditions and the response selected for
your application.
Implement Status Switch
When the operator selects the "Hold" condition, deactiva-
tion of the Implement Status switch (open circuit) hold’s
the flow control valve in its current position. When
Measured distance
Indicated distance
x Old DC# = New DC#
400
396
x 760 = 768, the New DC#
