B-2
TASC 6100
98-05018
R2
CE & S TANDARD V ERSION
Appendix B S
YSTEM
O
VERVIEW
How The TASC 6100 Controls Application Rate
T
he TASC 6100 system is designed as a control
ler for both liquid and granular application.
There are two independent programs in the
console, one for liquid and one for granular. The
operator can select either program with a simple
switch activation. Calibration constants that are set in
the granular program stay in memory, even if the
corresponding constants are changed in the liquid
program. This allows a single console to be moved
between a spreader and a sprayer, without requiring
complete reprogramming.
The TASC 6100 system senses ground speed, active
application width, and product flow rate. A change in
ground speed or boom width results in a proportional
change of material flow rate to maintain a constant,
pre-selected application rate. Comparisons of flow
Fig. B-1 TASC 6100
System Data Flow
Boom Width
Data
Ground Speed
Data
Application Rate
Data
Rate Change
Commands
Operator/Console
Input
Mid-T
Mid-T
ec
ec
h
%Rate
DISPLAY SELECTOR
Speed
Area Width
Distance
Fan RPM
Test Speed
PSI/Prime
Total Applied
Product Vol. Appl. Rate
OFF SET- UP DEC.
ON OPERATE INC.
1 2 3 4 5 6 7 8 9
BOOMS
Scan
MID-TECH
MIDWEST TECHNOLOGIES, INC.
TASC-6100
Rate Controller
®
