86 V676 ® / V476 ® CONTROL CONSOLE USER MANUAL
Color
When [Color] is selected, the soft encoder mapping is as follows:
Page 1
Z Pos (open/other)
Wheel 2 (open/close)
Wheel (open/close) - also controls gel scrollers
Magenta (open/close)
Yellow (open/close)
Cyan (open/close)
Page 2
Z Index (open/other)
Y Index (open/other)
X Index (open/other)
Color 8 (open/close)
Color 7 (open/close)
Color 6 (open/close)
Beam
When [Beam] is selected, the soft encoder mapping is as follows:
Page 1
Beam 2 (open/close)
Frost (in/out)
Strobe (stop/max)
Zoom (large/small)
Edge (hard/soft)
Beam (open/close)
Page 2
Prism Index (open/other)
w/ [Shift] button pressed - Rotate (stop/max)
Prism (in/out)
w/ [Shift] button pressed - Spin (stop/max)
OutFrame (open/other)
InFrame (open/other)
PlayMode (open/other)
PlaySpeed (open/other)
