Preparing for Operation

3-24

Positioner SIPART PS2/SIPART PS2 PA

C79000-G7476-C150–01

Set restrictors to
prolonged actuating
time s. Section 2.2.6

Actuating times

> 1.5 s ?

Actuator up
direction ascer-
tain pulse-stop
time down up

blinks

altern.

Actuator stops

within

5s

within

5s

Actuator stops

after

1 Min.

Actuator down
direction ascer-
tain pulse-stop
time up down

yes

yes

no

no

no

yes

Actuating time [s] too small

Actuating time [s]

Leakage display
[%/min]

RUN 4

RUN 3

3

Actuator to y = 50 % positioning
increments,

"

y with variable

pulse width, ascertain minimum

pulse-stop increments

Closed control loop w = 50 %
optimize transient response
ascertain prediction horizon

Configuring

Real travel [mm] or angle of rotation [degrees]
also indication that initialization is complete

RUN 5

1)

2)

If you wish to set the
actuating time

If you want leakage
test of actuator

continue
using:

continue using:

continue using:

Manual operation

If short actuating
time desired

continue using:

Fig. 3-24

Initialization, part 3
