Technical Reference Page 8-5
Serial Communication Port
Connector Pinouts
Pin Description
2 RS-232C: Transmit Data (TD)
3 RS-232C: Receive Data (RD)
4 RS-232C: Request to Send (RTS)
5 RS-232C: Clear to Send (CTS)
6 RS-232C: Data Set Ready (DSR)
7 RS-232C: Signal Ground (SIG GND)
20 RS-232C: Data Terminal Ready (DTR)
22 Ring Indicator (RI)
16 Ring Excitation (RX)
1 Digital Input 1 (least significant)
8 Digital Input 2
11 Digital Input 3
13 Digital Input 4/Bar Code Wand Signal (most significant)
14 Digital Output 1 (least significant)
15 Digital Output 2
17 Digital Output 3 (most significant)
12 Light Pen Ground
25 Light Pen Power
13 Light Pen/Digital Input 4
21 Battery Charge High
19 Battery Charge Low
18 Transmit Clocked Serial (TXS)
23 Receive Clocked Serial (RXS)
24 Serial Clock (CKS)
9 Not Used
10 Not Used
25 14
1 13
