Page 5-18 Sending and Receiving Information
Operating Mode 3-2
After you are sure that the FieldBook and the other device are communicating properly,
enter Mode 3-2 on the FieldBook. The following screen is displayed:
LOAD SER FILE A mating call is sent from the computer to the
FieldBook and from the FieldBook to the computer.
The FieldBook begins to load the file. Each line of
the file appears on the lower line of the display as it
is received.
For more information, refer to Section 3, Operating System, Operating Modes, Mode 3-2: Load
Serial File for more details on using Mode 3-2.
▲ ▲ ▲ ▲ ▲ Mode 3-3: Loading a Memory Image
Mode 3-3 is used to load a memory image onto the FieldBook from a computer or another
FieldBook. All the files, operating system variables, attributes, user registers, etc. are loaded.
This feature is useful for loading a clone of one FieldBook's memory onto another FieldBook.
Setting up Another FieldBook to Transmit a Memory Image to the FieldBook
If you are loading a memory image from another FieldBook, the FieldBooks must have
identical memory sizes. The receiving FieldBook must be in Mode 3-3 and the sending
computer in Mode 2-3. Set the communication parameters up as follows:
- Set the mating call on the receiving FieldBook to match the line request character on the
transmitting FieldBook.
- Set the input line terminator on the receiving FieldBook to match the end-of-line sequence
on the transmitting FieldBook.
Operating Mode 3-3
After you are sure that the FieldBook and the other device are communicating properly,
enter Mode 3-3 on the FieldBook. The following screen is displayed:
LOAD SER MEM A mating call is sent from the computer to the
FieldBook and from the FieldBook to the computer.
The FieldBook begins to load the memory image.
For more information, refer to Section 3, Operating System, Operating Modes, Mode 3-3: Load
Serial Memory for more details on using Mode 3-3.
