Juniper Systems JS600 User Manual
Page 54
Page 5-12 Sending and Receiving Information
Operating Mode 2-3
After you are sure that the FieldBook and the other device are communicating properly,
enter Mode 2-3 on the FieldBook. The following screen is displayed:
XMIT SER MEM
Then:
CP=D
The bottom line shows the current settings of the
L=A R=B C=C S=D
line request, repeat request, continuous request, and
stop request characters. In the upper right corner is
the current parameter for the request character
currently in force.
Initiate transmission by keying in the line request or continuous request character, or execut-
ing your computer program so that it sends one of the request characters.
Refer to Section 3, Operating System, Operating Modes, Mode 2:Transmit for more details on
using Mode 2-3.
