Page 3-10 Operating System
▲ ▲ ▲ ▲ ▲ Mode 2: Transmit
The Transmit Mode has three submodes: Mode 2-1 Transmit Serial Data (XMIT SER DATA),
Mode 2-2 Transmit Serial File (XMIT SER FILE), and Mode 2-3 Transmit Memory Image
(XMIT SER MEM).
Mode 2-1 Transmit Serial Data
The Transmit Data submode is used to transmit the contents of a data file through the
RS-232C port to another device. Instructions for using Mode 2-1 follow.
Keyboard Entry Next Message Shown Action
MODE? Enter a 2 for XMIT SER Mode.
2 XMIT SER 1,2,3 Enter a 1 for submode DAT.
DAT, FILE, MEM
1 XMIT SER DATA Enter the filename containing the file to be
FILE: transmitted or select the name using the right
or left arrow key.
Filename L 1 P 1 CP=D “L 1 P 1” indicates the current line and page
L=A R=B C=C S=D numbers. Data will be transmitted beginning
at the current line.
The bottom line shows the current settings of
the line request, repeat request, continuous
request, and stop request characters. In the
upper right corner is the current parameter
or the request character currently in force.
Guide to Transmitting Serial Data
❏ To initiate transmission, send a request character from the connected device or key it in
on the FieldBook's keyboard.
❏ The output format depends on the format file associated with the data file (refer to Mode
1-2) and data transmission protocol settings (refer to Mode 5-2).
❏ The checksum, if enabled, and the end-of-line sequence trail each line, including column
heading lines. One blank is output between the data line and the checksum. The blank is
not counted in calculating the checksum.
❏ Column headings are transmitted at the top of each page if transmit prompts (XMIT
PMTS) is set to Y in Mode 5-2.
❏ An end-of-page sequence is transmitted at the end of each page and an end-of-file
sequence is transmitted at the end of the file.
