Page 7-20 PolyTools Program
Select the Test Terminal Mode submenu option. The following screen appears:
Connect the FieldBook to the computer with the proper RS-232 communication cable. Turn on
the FieldBook and get into Terminal Mode by invoking Mode 7-3.
Press any character on the FieldBook. The same character you typed in should be
displayed on the Receive portion of the computer screen. Press any key on the computer
keyboard. This character should be displayed on the FieldBook screen. If the character you
typed is displayed on the Send or Receive portion of the computer screen and on the FieldBook
screen, the parameters are set up correctly and the machines are communicating. If the charac-
ters do not match, check the communication parameter settings on the FieldBook and the
computer and make the necessary corrections. If you are still unable to
establish communication, check your cable connections and the settings for the port.
You are now ready to transfer files between the computer and the FieldBook.
▲ ▲ ▲ ▲ ▲ Sending Files From the Computer to the FieldBook
Setting up the Computer to Send Information
To send a file from the computer to the FieldBook, select the Send to FldBook submenu. The
following information is displayed on the screen:
To view a listing of files, press . Scroll through the list until the desired filename is
highlighted, then press . The selected filename is displayed. You can also type in the
name of the file followed by the proper filename extension and press .
Receive
Send
Esc: Finish
Enter Filename: _________________________
F1: help F2: show files ESC: exit RETURN: accept
