Operating System Page 3-11

Mode 2-2 Transmit Serial File
The Transmit Serial File submode is used to transmit a data, format, or program file through
the RS-232C port to another device. Instructions for using Mode 2-2 follow.

Keyboard Entry

Next Message Shown

Action

MODE?

Enter a 2 for TRANSMIT Mode.

XMIT SER 1,2,3

Enter a 2 for submode FILE.

DAT, FILE, MEM

XMIT SER FILE

Enter the filename to be transmitted or select

FILE:

the name using the right or left arrow key.

Filename

L 1 P 1 CP=D

“L 1 P 1” indicates the current line and page

L=A R=B C=C S=D

numbers. For format and program files, the
page field is vacant. The entire file is
transmitted regardless of the line number.

The bottom line shows the current settings of
the line request, repeat request, continuous
request, and stop request characters. In the
upper right corner is the current parameter
or the request character currently in effect.

Output Formats

DAT

<

Data lines with column leaders embedded; checksums follow

if CHECKSUM is set to Y; column prompts not sent even if

XMIT PMTS set to Y.

FMT

<

Column number, period; then column format, column

prompt, and column leader, delimited by asterisks.

PGM

<

Polycode program with line number ending with a period, opcode, >

mnemonic, and parameter delimited by blanks.
